| Place of Origin: | China |
|---|---|
| Brand Name: | YUBEI |
| Certification: | ISO9001 |
| Minimum Order Quantity: | 100pcs |
| Price: | Negotiate |
| Packaging Details: | carton or wooden case or pallet packing |
| Delivery Time: | 30 work days |
| Supply Ability: | 1000pcs one month |
| Product Name: | Insulating Alumina Ceramic | Material: | 99% Al2O3 |
|---|---|---|---|
| Dielectric Constant: | 10 | Thermal Conductivity: | 29W/mK |
| Compressive Strength: | 2300MPa | Bending Strength: | 310MPa |
| High Light: | 2300MPa Insulating Ceramics,Insulating Ceramics Corrosion Resistant,ISO9001 Alumina Based Ceramics |
||
Supply Insulating Alumina Ceramics Base Aluminum Oxide Ceramic
Alumina Ceramic is a material highly regarded and widely used of the ceramic products. It is non-conductive, resistant to corrosion, and perfect for electrical insulation. Alumina ceramic has been proven to be the best ceramic for protection of vital electrical components. It can be processed as tubing, sheets, bars, rods, discs, and many other forms depending on the requirements of the project.
Manufacturing:
| Material | 95% or 99% AL2O3 |
| Size | Customize by drawings or samples |
| Pressing process | dry pressing, cold isostatic pressing, hot press moulding technique |
| Finish machining | Lathe, grinding machines, milling machine, carving machines, etc. |
| Delivery time | 30-35 days |
| Packing | Cartons, wooden case or pallet |
| FOB port | Shanghai port |
Characteristics of alumina ceramics:
Applications for alumina ceramics:
Alumina ceramics can be applied in many fields, such as electronics, machinery, medical, textile industry, shipping, pump, steel industry, kiln and furnace fittings, etc.
| Properties | Item | Unit | 99% Alumina | 95% Alumina |
| Mechanical Property | Color | -- | Light Yellow | White |
| Mechanical Property | Density | g/cm3 | 3.85 | 3.6 |
| Mechanical Property | Bending Strength | MPa | 310 | 300 |
| Mechanical Property | Compressive Strength | MPa | 2400 | 2300 |
| Mechanical Property | Elastic Modulus | GPa | 340 | 320 |
| Mechanical Property | Fracture Toughness | MPam1/2 | 3-4 | 3-4 |
| Mechanical Property | Weber Coefficient | m | 12 | 12 |
| Mechanical Property | Vickers Hardness | HV0.5 | 1600 | 1400 |
| Thermal Property | Coefficient of Line Thermal Expansion | 10-6K-1 | 7-8 | 7-8 |
| Thermal Property | Thermal Conductivity | W/mK | 29 | 20 |
| Thermal Property | Thermal Shock Resistance( in water) | ΔT℃ | 200 | 250 |
| Thermal Property | Max Working Temperature | ℃ | 1600 | 1500 |
| Electrical Property | Volume Resistance at 20℃ | Ωcm | >1014 | >1014 |
| Electrical Property | Dielectric Strength | V/m | 15X106 | 15X106 |
| Electrical Property | Dielectric Constant | εr | 10 |
9 |
95% Alumina Insulating Ceramic
FAQ:
1. Are you a factory?
Yes, we're a factory professinally producing industrial ceramics. Our main products are alumina ceramics, zirconia ceramics and sic ceramics.
2. What's the size of it?
Products are always customized according to drawings or samples. Diameter and height within 500mm are available.
3. What's the price for it?
It depends. Prices are caculated by the drawing size and structure.
4. What's the production process?
Our products are made mainly in cold isostatic pressing, dry pressing and hot press moulding technique.
5. How about the delivery?
Generally speaking, a ceramic production needs about 30 days to finish. Some special products maybe take a longer time. For some simple products, maybe 10-15 days is ok.
6. How's the packing?
The usual packing is cartons, wooden cases, or pallets. Ceramics are fragile products, will use some breakage-proof materials to protect them.
7. Can you do the finish maching?
Yes, we have lathes, grinding machines, milling machines, carves-milling machines to make sure products' accuracy.
8. Which is the nearest port?
Shanghai port is the nearest one from us. It takes about 2-3 hours to get to shanghai port.
